IN-R - Large Display Tachometer Indicator with relay output options:

Product Specifications:

Download IN-Series Process Indicators Sales Brochure

Download Installation Guide

Description:

The IN-R is a technically advanced but cost effective microprocessor-based indicator designed specifically for use in tachometer applications. Options for up to four relay outputs make it ideal for stand-alone control or as a PLC interface. Intuitive scrolling text menus, (activated from the front panel), guide you step by step through the setup and calibration process, and the large 4-digit display ensures that the figures can be easily read from a distance.

Features:

• Large 4 Digit LED Display.
• Microprocessor Based for Wide Range Calibration.
• Inputs: 0~30V, magnetic pickup, NPN, PNP, TTL, Namur.
• 4 Set Points with delay.
• 4 LED’s for Alarm indication.
• Analogue Output Retransmission option.
• Simple setup and calibration.

• On Screen Step by Step Instructions.

• 5 Buttons for easy Operator Interface.

• Wide Range of Power Supply options from 10V to 265V.
• Excitation supply 24Vdc.

Ordering Information:

IN-R-X

Standard calibration Tachometer; 4x 5A relay outputs, 85~265Vac / 95~370Vdc Power supply.
