□ DIN Size 48 x 96 mm
□ ± 0.3% High Accuracy Indication
□ Large 20 mm bright display
Make reading from long distance and low light location easier
□ Multi-inputs & Multi-ranges
User selectable Thermocouple, RTD,V, mV and Current inputs
A 250Ω resistor is required across the input terminal for 4-20mA DC
□ Inverse scaling possible
With voltage and current input signals, normal and inverse scaling is possible.
Additionally, normal and inverse scaling is possible for the analog output signals.
□ Dust and splash proof front panel Equivalent to IP66
□ Wide range of optional features
Alarms, analog output signals and communication interface
(RS-232C or RS-485: MODBUS / Shimaden) available
Sensor power supply 24V DC available
□ A six-point selector switch, (the KR16 series), is available for combined use.
