Shimaden MR13 - multi input controller

• LED display:

• Action display LED:

• Display accuracy:

• Temperature range in
which accuracy is
maintained:

• Display resolution:

• Sampling cycle:

• Measured value
display range:

Setting
• Setting:

• Setting range:

• Higher/lower limit
setting limiter:

• Follow type SV:

Input
• Input type has to be the same for 3 channels (measuring range
can be selected individually).

• Thermocouple:

External resistance:

Input impedance:

Burnout:

Cold junction temperature
compensation accuracy:

• R.T.D.:

Amperage:

Lead wire tolerable
resistance:

• Voltage:

Input impedance:

Current:

Receiving impedance:

• Sampling cycle:

• PVbias:

• PV filter:

• Follow type PV input:

• Isolation:

Control
• Control mode:

Proportional band (P):

Integral time (I):

Derivative time (D):

Manual reset:

ON/OFF hysteresis:

• Proportional cycle:

• Control output
characteristics:

• Output limiter:

• Soft start:

Control output/rating
• Output specification has to be the same for 3 channels.
• Contact output (Y):

• Current output (I):

• SSR drive voltage
output (P):

• Voltage output (V):

• Operation output
updating cycle:

• Isolation:

Event output (optional)
• Number of outputs:

• Output rating:

• Setting:

• Hysteresis:

• Standby action:

• Action delay time:

• Isolation:

Remote setting (optional, selectable between this function and Dl)
• Setting signal:

• Setting range:

• Accuracy of setting:

• Channel for setting:

• Remote scaling:

• Remote bias:

• Remote filter:

• Sampling time:

• Isolation:

External control input (Dl) (optional, selectable between this
function and remote setting)
• Number of input point:

• Input rating:

•Action type:

• Isolation:

Program (optional)
• Registrable pattern:

• Number of steps:

• Program setting range
Level:

Time:

Ramp:

• Number of executions:

• PID output limiter:

• External control input:

• Action status output:

• CH2 and CH3 in
SV follow setting:

• Additional functions:

Analog output (optional, selectable between this function and
communication)
• Number of output:

• Output types:

• Output rating:

• Output accuracy:

• Output resolution:

• Output updating cycle:

• Output scaling:

• Isolation:

• Communication address:

• Communication code:

• Communication
protocol:

• Communication format:

• Isolation:

• Others:

Others
• Data storage:

• Ambient temperate/
humidity ranges:

• Temperature
for storage:

• Power voltage:

• Power consumption:

• Input noise
removal ratio:

• Applicable standard
Safety:

EMC EMI (emission):

EMS (immunity):

• Insulation resistance:

• Dielectric strength:

• Protective structure:

• Material:

• External dimensions:

• Mounting:

• Panel cutout size:

• Weight:

PV display 7-segment LED green 4
digits 3 channels to be displayed
individually.
SV display 7-segment LED orange 4
digits
CH display 7-segment LED orange 1
digit

Control output display: 3 - OUT1,
OUT2, OUT3 .
Auto tuning: 1 - AT
Follow type SV display: 1 - FLW
Program RUN: 1 - RUN
Event output display: 3 - EV1, EV2,
EV3
Remote input display: 1 - REM
Communication display: 1 - COM

±(0.3%FS + 1 digit) Standard
accuracy

230°C±50°C

Depends on measuring range
(0.001, 0.01, 0.1,1)

0.5 seconds

-10% to 110% of measuring range

By 6 front key operation

Same as measuring range

Higher and lower limits to be set
separately; free within measuring
range (Lower limit < higher limit)

SV of CH2 or CH3 can be set to
follow CH1 (deviation setting) (on
condition that measuring range of
CH2 or CH3 is the same as that of
CH1.)

B, R, S, K, E, J, T, N, PL II, WRe5-26,
{L, U (D1N43710)}
(Multiple input, multiple range. Refer
to measuring range code table.)

100 Ohm maximum

500k Ohm minimum

Standard feature (up scale)

±2.0 °C (5~45 °C)

JIS Pt100/JPt100 3-wire type
(Multiple range. Refer to measuring
range code table.)

Approx. 025 mA

5 Ohm maximum/wire

±10, 0~10, 0~20, 0~50, 10~50,
0~100mV DC, or ±1, 0~1, 0~2, 0~5,
1~5, 0~10V DC
(Multiple-input, programmable range.
Refer to measuring range code
table.)

500k Ohm minimum

4~20, 0~20mA DC
(Multiple input, programmable range.
Refer to measuring range code
table.)

250 Ohm

0.5 seconds

±1999 units

OFF, 1~100 seconds

PV input of CH2 or CH3 can be set
to follow CH1 (deviation setting) (on
condition that measuring range of
CH2 or CH3 is the same as that of
CH1.)

Insulated between input and various
outputs (not insulated between input
and system, remote input and DI
input)

Expert PID control with auto tuning
function

OFF, 0.1~999.9%FS
(OFF=ON/OFF action)

OFF, 1~6000s (OFF=P, PD action
with manual reset)

OFF, 1~3600s (OFF=P, P1 action)

±50.0%

1~999 units

0.5~120.0 seconds
(0.5 sec. is unit for setting.)

RA/DA selectable (set to RA when
shipped)

Higher limit, lower limit 0.0~100.0%
(lower limit. < Higher limit)

OFF, ON (Fixed to 10 sec.; Valid
when power is turned on, RTS ->
RUN, and when returned from
scaleover.)

1 a 240V AC 2.5A/resistive load

4~20mA, 0~10mA DC/
load resistance 600 Ohm maximum.

15V±3V DC/
Load current 20mA maximum

0~10V DC/
Load current 2mA maximum

0.5 second

Insulated between control output and
system and input
(not insulated between control output
I, P or V and analog output)

3 -EV1, EV2, EV3 (Selectable from
CH1, CH2 and CH3, individual
setting, individual output)

Contact output la (common) 240V
AC/ 1A (resistive load)

Individual setting
0) NON: Not assigned
1) DEV: Higher limit deviation value
alarm
2) DEV: Lower limit deviation value
alarm
3) DEV: Higher/lower limit value
alarm in case SV is out of
measuring range
4) DEV: Higher/lower limit value
alarm in case SV is within
measuring range
5) PV: Higher limit absolute value
alarm
6) PV: Lower limit absolute value
alarm
7) SO: ON upon scaleover
8) RUN: ON during program RUN
9) END: ON for 1 sec. upon
termination of program
10) STEP: ON for 1 sec. upon
termination of program step

1~999units
(when DEV or PV has been selected)

Selectable
(when DEV or PV has been selected)

OFF, 1~9999 seconds
(when DEV or PV has bean selected)

Insulated between alarm output and
various inputs/outputs and system

1~5V, 0~10V, 4~20mA

Same as measuring range

±(0.3%SF + 1) digit

Selectable from CH1, CH2 and CH3

Within measuring range (inverted
scaling possible)

-1999~5000 units

OFF, 1~100 seconds

0.5 second

Insulated between remote input and
various outputs (not insulated from
system and various inputs)
Others

1

Non-voltage contact, open collector
input (about 5V/0.4mA DC impress)

NON, FLW (follow type SV), RST/
RUN, HLD and ADV

Insulated between Dl input and
various outputs (not insulated from
system and various inputs)

1

9 maximum

Same as measuring range

1~9999 minutes/step

To be set automatically according to
level and time

9999 maximum

To be set selectively from 3 types of
PID & output limiter

Dl/non-voltage 1 point (RUN/RST,
HLD, ADV)

RUN, END and STEP to be
selectively output to event output

Program to be executed by making
CH2 or CH3 deviation-follow to
pattern set in CH1 in SV follow
setting. Not in SV follow setting,
program is executed in FIX mode.

Temporary suspension (HLD), carry-
forward (ADV), PV start

1

Selectable from CH1_PV, CH2_PV,
CH3_PV, CH1_SV, CH2_SV, CH3_SV,
CH1_OUT, CH2_OUT and CH3_OUT

0~10mV DC/Output impedance 10 Ohm
0~10V DC/Load current 1 mA
maximum
4~20mA DC/Load resistance 300 Ohm
maximum

±0.3%FS (to displayed value)

Approx. 1/8000

0.5 seconds

Within measuring range (inverted
scaling possible)

Insulated between analog output and
various inputs and system (not
insulated between analog output and
control outputs I, P and V)

1~99

ASCII code

Shimaden standard protocol

Control code selectable, BCC check
arithmetic system selectable

Insulated between communication
signal and system/input/output

Meets the EMC standards with an
additional clamp filter
(E04SR301334, SEIWA Information
Systems Co.,LTD)

By non-volatile memory (EEPROM)

-10~+500C/below 90% RH
(on condition that there is no dew
condensation)

Between-20 and +65 C

100V~260V AC ±10% (50/60 Hz)

12VA maximum

Normal mode 45 dB minimum
(50/60 Hz)
Common mode 140 dB minimum
(50/60 Hz)

IEC1010-1 / EN61 010-1

EN50081 -2: 1993

EN50082-2: 1995

Between input/output terminals and
power terminal: 500V DC 20M Ohm
minimum
Between input/output terminals and
protective conductor terminal: 500V
DC 20M Ohm minimum

1 minute at 2300V AC between
input/output terminals and power
terminal (inductive current 5mA)
1 minute at 2300V AC between
power terminal and ground terminal
(inductive current 5mA)

Only front panel has simple dust-
proof and drip-proof structure

PPO resin molding (equivalent to
UL94V-1)

96 x 96 x 110 mm
(Panel depth: 100 mm)

Push-in panel (one-touch mount)

H92 x W92 mm

Approx. 420 g
